Pulsation Dampener

Pulsation Dampener

 Features

  • Pressure storage equipment for pressurized liquids


  • Bladder absorb pulse pressure


  • No restrictions on installation direction

 Features

  • Pressure storage equipment for pressurized liquids


  • Bladder absorb pulse pressure


  • No restrictions on installation direction

Pulsation Dampener

608N Pulsation Dampener




Material of Construction

No.

Parts Name

Material

1

Protective Cover

Ductile Iron

2

Pressure Gauge

3

Charging Port

Brass

4

Ball Valve

Brass

5

Cover

Cast Steel / Stainless Steel

6

Bladder

NBR / EPDM / VITON

7

Body

Cast Steel / Stainless Steel





Dimension

Size (DN)

H (mm)

D (mm)

Capacity (L)

50*

240

180

0.7

65

355

300

3

80

355

300

3

100

425

370

6

125

425

370

6

150

500

505

17

200

565

570

30

250

565

570

30

300

565

570

30

*No protective cover





Note:

※King-Tech reserves the right to make any revisions on the valve model and size without prior notification.


Specification

Connection:Flange – PN10 / 16、JIS 10K / 16K / 20K

Max working pressure:25 Bar

Max work temperature:100℃ / 220℃







Download

Catalog Of 608N Pulsation Dampener
